VisualFreeBasic游戏趣味编程_9.5_游戏胜利判断

勇芳
2026-1-22 / 0 评论 / 49 阅读

当玩家把所有箱子推到目标位置时游戏胜利，如图9-6所示。

首先定义全局变量存储地图中目标位置的个数、完成目标的个数：

Dim Shared As Long targetNum,achievedNum  '目标位置个数、完成目标个数

在startup()函数中对二维数组进行遍历，如果地图元素为target或achieved，则将目标个数targetNum加1：

Sub startup() '初始化函数
   Dim i As Long, j As Long
   targetNum = 0 ' 目标个数，初始为0
   For i = 0 To B_NUM -1 '遍历关卡二维数组数据
      For j = 0 To B_NUM -1
         If Mid(level(i), j + 1, 1) = "p" Then '找到地图中player的位置
            Players.i = i '设定player的位置
            Players.j = j
            Mid(level(i), j + 1, 1) = "e" '把地图元素变成空白empty
         ElseIf Mid(level(i), j + 1, 1) = "t" Or Mid(level(i), j + 1, 1) = "a" Then ' 如果元素是target或achieved
            targetNum += 1 '目标个数+1
         End If
      Next
   Next
End Sub

在update( )函数中统计元素更新后的完成目标个数：

         Dim i As Long, j As Long
         achievedNum = 0 ' 完成目标个数，初始为0
         For i = 0 To B_NUM -1 '遍历关卡二维数组数据
            For j = 0 To B_NUM -1
               If Mid(level(i), j + 1, 1) = "a" Then ' 如果元素是achieved
                  achievedNum += 1 '完成目标个数+1
               End If
            Next
         Next

如果完成目标个数等于目标个数，在show( )函数中显示游戏胜利信息：

   If (achievedNum = targetNum) Then ' 如果完成目标个数等于目标个数
      gg.Font "黑体", 30
      gg.SetColor BGR(0,255,255) 'GDI的颜色值。
      gg.DrawString 15,100,"游 戏 胜 利"
   End If

读者可以自己更改代码，看看是否和预料的结果一样。如果不同，自己试着排除错误。
完整代码如下：

Type Player ' 结构体，用于记录玩家位置
   i As Long
   j As Long
End Type

#define B_SIZE 32        ' 方块大小
#define B_NUM 8          ' 方块个数,一共8*8个方块
'用字符型二维数组存储地图数据
'e: empty w: wall t: target b: box a: achieved p:player
'全局变量定义
Dim Shared level(B_NUM -1) As ZString * B_NUM + 1 = {"wwwwwwww", "wwwtbeew", "weeeeeew", "weeeeeew", "weeeeeew", "weepaeew", "weeewwww", "wwwwwwww"}
Dim Shared Players As player '玩家全局变量
Dim Shared As Long targetNum, achievedNum '目标位置个数、完成目标个数
Sub startup() '初始化函数
   Dim i As Long, j As Long
   targetNum = 0 ' 目标个数，初始为0
   For i = 0 To B_NUM -1 '遍历关卡二维数组数据
      For j = 0 To B_NUM -1
         If Mid(level(i), j + 1, 1) = "p" Then '找到地图中player的位置
            Players.i = i '设定player的位置
            Players.j = j
            Mid(level(i), j + 1, 1) = "e" '把地图元素变成空白empty
         ElseIf Mid(level(i), j + 1, 1) = "t" Or Mid(level(i), j + 1, 1) = "a" Then ' 如果元素是target或achieved
            targetNum += 1 '目标个数+1
         End If
      Next
   Next
End Sub

Sub show(gg As yGDI) '绘制函数
   gg.Cls BGR(150, 150, 150) '灰色背景。
   Dim i As Long, j As Long

   For i = 0 To B_NUM -1 '遍历关卡二维数组数据
      For j = 0 To B_NUM -1
         If Mid(level(i), j+1, 1) = "e" Then 'empty元素是空白区域
            gg.Pen 0, 0 '框
            gg.Brush BGR(150, 150, 150) '绘制灰色地面
            gg.DrawFrame j *B_SIZE, i *B_SIZE, B_SIZE, B_SIZE
         ElseIf Mid(level(i), j+1, 1) = "w" Then 'wall元素是墙
            gg.Pen 1, BGR(120, 120, 120) '框
            gg.Brush BGR(155, 0, 0) '绘制淡红色、灰色线的方框
            gg.DrawFrame j *B_SIZE, i *B_SIZE, B_SIZE, B_SIZE
         ElseIf Mid(level(i), j+1, 1) = "b" Then 'box元素是可移动的箱子
            gg.Pen 1, BGR(150, 150, 150) '框
            gg.Brush BGR(255, 255, 0) '绘制一个黄色的方块
            gg.DrawFrame j *B_SIZE, i *B_SIZE, B_SIZE, B_SIZE
         ElseIf Mid(level(i), j+1, 1) = "t" Then 'target元素是目标
            gg.Pen 0, 0 '框
            gg.Brush BGR(255, 255, 255)
            gg.DrawFrame(j + 0.25) *B_SIZE, (i + 0.25) *B_SIZE, B_SIZE * 0.5, B_SIZE * 0.5
         ElseIf Mid(level(i), j+1, 1) = "a" Then 'achieved 元素是已完成目标
            gg.Pen 0, 0 '框
            gg.Brush BGR(255, 255, 0) '绘制一个黄色的方块
            gg.DrawFrame j *B_SIZE, i *B_SIZE, B_SIZE, B_SIZE
            gg.Pen 1, BGR(150, 150, 150) '框
            gg.Brush BGR(255, 255, 255)
            gg.DrawFrame(j + 0.25) *B_SIZE, (i + 0.25) *B_SIZE, B_SIZE * 0.5, B_SIZE * 0.5
         ElseIf Mid(level(i), j+1, 1) = "p" Then 'player 元素是玩家，绘制一个人脸图案

         End If
      Next
   Next
   i = Players.i
   j = Players.j
   '一个红色圆脸
   gg.Pen 0, 0 '框
   gg.Brush BGR(255, 0, 0) '一个红色圆脸
   gg.DrawEllipse(j + 0.1) *B_SIZE, (i + 0.1) *B_SIZE, B_SIZE * 0.8, B_SIZE * 0.8
   '两个黑色眼睛
   gg.Brush BGR(90, 90, 90) 'GDI的颜色值。
   gg.DrawEllipse(j + 0.2) *B_SIZE, (i + 0.35) *B_SIZE, B_SIZE  * 0.25, B_SIZE * 0.25
   gg.DrawEllipse(j + 0.55) *B_SIZE, (i + 0.35) *B_SIZE, B_SIZE * 0.25, B_SIZE * 0.25
   '一个深灰色嘴巴
   gg.DrawFrame(j + 0.3) *B_SIZE, (i + 0.7) *B_SIZE, B_SIZE * 0.4, B_SIZE * 0.1
   If (achievedNum = targetNum) Then ' 如果完成目标个数等于目标个数
      gg.Font "黑体", 30
      gg.SetColor BGR(0,255,255) 'GDI的颜色值。
      gg.DrawString 15,100,"游 戏 胜 利"
   End If
   gg.Redraw
End Sub

Sub updateWithoutInput() '与输入无关的更新

   Sleep 10  '暂停若干毫秒
End Sub
Sub updateWithInput(hWndForm As hWnd, gg As ygdi) ' 和输入有关的更新
   Static pp As Long '预防一直按下，造成一直移动
   If pp = 1 Then
      If IsKeyPress(&H57) = 0 And IsKeyPress(&H53) = 0 And IsKeyPress(&H41) = 0 And IsKeyPress(&H44) = 0 Then
         pp = 0
      End If
   Else
      If IsKeyPress(&H57) Then ' 上
         pp = 1
      ElseIf IsKeyPress(&H53) Then ' 下
         pp = 1
      ElseIf IsKeyPress(&H41) Then ' 左
         pp = 1
      ElseIf IsKeyPress(&H44) Then '  右
         pp = 1
      End If
      If pp = 1 Then
         Dim goal_i     As Long = players.i ' 移动的目标位置
         Dim goal_j     As Long = players.j
         Dim goalNext_i As Long = goal_i '目标位置再向前的一个位置
         Dim goalNext_j As Long = goal_j
         ' 根据用户的不同按键输入,获得目标位置、再向前的一个位置
         If IsKeyPress(&H57) Then ' 上
            goal_i     = Players.i - 1 ' 目标位置在玩家位置的下边
            goalNext_i = goal_i    - 1 ' 目标的下一个位置,在其再下边
         ElseIf IsKeyPress(&H53) Then ' 下
            goal_i     = Players.i + 1 ' 目标位置在玩家位置的下边
            goalNext_i = goal_i    + 1 ' 目标的下一个位置,在其再下边
         ElseIf IsKeyPress(&H41) Then ' 左
            goal_j     = Players.j -1 ' 目标位置在玩家位置的左边
            goalNext_j = goal_j -1    ' 目标的下一个位置,在其再左边
         ElseIf IsKeyPress(&H44) Then '  右
            goal_j     = Players.j + 1 ' 目标位置在玩家位置的右边
            goalNext_j = goal_j    + 1 ' 目标的下一个位置,在其再右边
         End If
         '根据不同地图元素的情况，判断如何移动角色和更新地图元素
         If Mid(level(goal_i), goal_j + 1, 1) = "e" Or Mid(level(goal_i), goal_j + 1, 1) = "t" Then
            '如果目标位置是empty，或者target
            Players.i = goal_i
            Players.j = goal_j
         ElseIf Mid(level(goal_i), goal_j + 1, 1) = "b" And Mid(level(goalNext_i), goalNext_j + 1, 1) = "e" Then
            ' 如果目标位置是box，再前面一个是empty
            Players.i = goal_i ' 玩家移动到目标位置
            Players.j = goal_j
            Mid(level(goal_i), goal_j + 1, 1)         = "e" ' 目标位置变成empty
            Mid(level(goalNext_i), goalNext_j + 1, 1) = "b" ' 再前面变成box
         ElseIf Mid(level(goal_i), goal_j + 1, 1) = "b" And Mid(level(goalNext_i), goalNext_j + 1, 1) = "t" Then
            ' 如果目标位置是box,再前面一个是target
            Players.i = goal_i ' 玩家移动到目标位置
            Players.j = goal_j
            Mid(level(goal_i), goal_j + 1, 1)         = "e" ' 目标位置变成empty
            Mid(level(goalNext_i), goalNext_j + 1, 1) = "a" '再前面变成achieved
         ElseIf Mid(level(goal_i), goal_j + 1, 1) = "a" And Mid(level(goalNext_i), goalNext_j + 1, 1) = "e" Then
            '如果目标位置是achieved,再前面一个是empty
            Players.i = goal_i ' 玩家移动到目标位置
            Players.j = goal_j
            Mid(level(goal_i), goal_j + 1, 1)         = "t" ' 目标位置变成target
            Mid(level(goalNext_i), goalNext_j + 1, 1) = "b" ' 再前面变成box
         ElseIf Mid(level(goal_i), goal_j + 1, 1) = "a" And Mid(level(goalNext_i), goalNext_j + 1, 1) = "t" Then
            '如果目标位置是achieved,再前面一个是target
            Players.i = goal_i ' 玩家移动到目标位置
            Players.j = goal_j
            Mid(level(goal_i), goal_j + 1, 1)         = "t" ' 目标位置变成target
            Mid(level(goalNext_i), goalNext_j + 1, 1) = "a" ' 再前面变成achieved
         Else '其他情况都推不动
            Return ' 不做任何处理,函数直接返回
         End If
         Dim i As Long, j As Long
         achievedNum = 0 ' 完成目标个数，初始为0
         For i = 0 To B_NUM -1 '遍历关卡二维数组数据
            For j = 0 To B_NUM -1
               If Mid(level(i), j + 1, 1) = "a" Then ' 如果元素是achieved
                  achievedNum += 1 '完成目标个数+1
               End If
            Next
         Next
      End If
   End If
End Sub
Sub 游戏执行过程(hWndForm As hWnd)
   Dim gg As yGDI = hWndForm
   startup()
   Do
      show(gg)
      updateWithInput(hWndForm, gg)
      updateWithoutInput()
   Loop

End Sub
